Unit Module	Item	Parameter
	Model Number	In-csc-Pro-series
	Module size	240mm*240mm
	Pixel pitch	1.875mm
	Pixels Density	284444dots/m2
	Pixel configuration	1R1G1B
	Package mode	SMD1010/SMD1515
	Pixel resolution	128dots(W)*128 dots(H)
	Max Power consumption	18.5W
	Module thickness	240mm*15mm（without magnets）
		242mm*15mm（with magnets）
	Weight	0.3kg
	Drive type	Constant drive
	Scan mode	1/32scan
	Port type	RVcard+Hub-A
	Brightness of white balance	≥880cd/m2
Cabinet	Dimension	480mm*480mm*65mm
	Quantity of Module	4
	Power supply	5V/40A
	Thermal discharge	fanless design
	Pixel per cabinet	256*256
	Best viewing distance	1.875M～20M
	Best viewing angles	140°(W) 140°(H)
	Temperature	storage:-35℃～+85℃ working:-20℃～+50℃
	Operation humidity	10%-95%
	Thickness	65mm
Power	Working voltage	AC110-220V±10%
	Average Power consumption	180W/㎡
	Max.Power consumption	≤500W/㎡
	Current	≤20mA(single LED)
Main technical   parameter	Driving device	Constant current driver IC
	Refresh frequency	≥1920HZ
	Grey scale/colors	256levels of each color(RGB)/16.7M colors
	Lifespan	≥100000 hours
	Operating System	winxp/win 7/win8/win10
	Screen application	Indoor permanent installtion series
