Unit Module	Item	Parameter
	Model Number	P10-13 series
	Module size	/
	Pixel pitch	10.416(H)-13.88(W) mm
	Pixels Density	6912 dots/m2
	Pixel configuration	1R1G1B
	Package mode	DIP570
	Pixel resolution	144dots * 2dots
	Max Power consumption	22W
	Module thickness	60mm
	Weight	2.55kg
	Drive type	Constant drive
	Scan mode	Static / 4 Scan
	Port type	HUB75-A
	Brightness of white balance	≥7500cd/m2
Cabinet	Dimension	1500mm*250mm*70mm
	Quantity of Module	9
	Power supply	5V/40A
	Thermal discharge	fanless design
	Pixel per cabinet	144dots * 18dots
	Best viewing distance	10M～200M
	Best viewing angles	140°(W) 140°(H)
	Temperature	storage:-35℃～+85℃ working:-20℃～+50℃
	Operation humidity	10%-95%
	Thickness	66mm
Power	Working voltage	AC110-220V±10%
	Average Power consumption	≤180W/㎡
	Max.Power consumption	≤500W/㎡
	Current	≤20mA(single LED)
Main technical   parameter	Driving device	Constant current driver IC
	Refresh rate	≥1920HZ
	Grey scale/colors	256levels of each color(RGB)/16.7M colors
	MTBF	≥100000 hours
	Operating System	winxp/win 7/win8
	Screen application	Indoor permanent installtion series
